Unique 4 tunnel pit design
Powder coated white
Tek screw construction
Tri-fold product doors with (3) windows
(16) 4-tube inside access light fixtures
(2) 24″ Exhaust fans with 9′ duct packages including clean out and ARV
Heated air make-up system at 1.5 MBTU and 14,000 CFM with deluxe controls
Heater duct package with intake & discharge duct
Inside dimensions:
26′ 7″ X 14′ X 9′
Outside dimensions:
27’ 1” x 16’ 6” x 11’
Powder coated white
Tek screw construction
Tri-fold product doors with (3) windows
Personnel door with window
(16) 4-tube inside access T8 light fixtures
(1) 34” exhaust fan with 15′ duct package including clean out and ARV
Heated air make-up system at 1.5 MBTU and 14,000 CFM with Deluxe controls
Heater duct package with intake and discharge duct
Inside dimensions:
26’ 7” x 14’ x 9’
Outside dimensions:
27’ 1” x 14’ 6” x 11’
Powder coated white
Tek screw construction
Tri-fold product doors with (3) windows
Personnel door with window
Dual parts doors with (2) windows
Divider curtain at 24’/12’
(20) 4-tube inside access T8 light fixtures
(2) 30” exhaust fans with 15′ duct packages including clean out and ARV
Heated air make-up system at 2.1 MBTU and 20,000 CFM with waterborne controls
XL control panel upgrade – vehicle end/parts end/both ends
Heater duct package with intake and discharge duct
Inside dimensions:
36’ 3” x 14’ x 9’
Outside dimensions:
36’ 9” x 14’ 6” x 11’
3″ double wall insulated panels
Powder coated white
Tri-fold product doors with (3) windows
Personnel door with window
(14) LED light fixtures
(1) 34” exhaust fans with 15′ duct package including clean out and ARV
Heated air make-up system at 1.5 MBTU and 14,000 CFM with Deluxe controls
Heater duct package with intake and discharge duct
Inside dimensions:
26’ 7” x 14’ x 9′
Outside dimensions:
27’ 1” x 14’ 6” x 11’
3″ double wall insulated panels
Powder coated white
Tri-fold product doors with (3) windows
Personnel door with window
Dual parts doors with (2) windows
Divider curtain at 24’/12’
(18) LED light fixtures
(2) 30” exhaust fans with 15′ duct packages including clean out and ARV
Heated air make-up system at 2.1 MBTU and 20,000 CFM with waterborne controls
XL control panel upgrade – vehicle end/parts end/both ends
Heater duct package with intake and discharge duct
Inside dimensions:
36’ 3” x 14’ x 9’
Outside dimensions:
36’ 9” x 14’ 6” x 11’
Galvanized
Tek screw construction
Tri-fold product doors with (3) windows
Personnel door with window
(16) 4-tube inside access T8 light fixtures
(1) 34” Exhaust fans – 14,000 CFM
(1) 34″ x 15′ duct package including clean out and ARV
Inside dimensions:
26’ 7” x 14’ x 9’
Outside dimensions:
27’ 1” x 14’ 6” x 11’
Galvanized
Nut & Bolt / Tek screw construction
Solid product doors without windows
Personnel door with window
(12) 4-tube T8 light fixtures
(1) 30” Exhaust fans with 15′ duct package including clean out and ARV
Heated air make-up system at 1.2 MBTU and 12,000 CFM with Deluxe controls
Heater duct package with intake and discharge duct
Inside dimensions:
26’ x 14’ x 9’
Outside dimensions:
26’ 5” x 14’ 5” x 11’
