Powder coated white
Tek screw construction
Solid product doors with (2) windows
Personnel door with window
(12) 4-tube inside access T8 light fixtures
(1) 30” exhaust fan with 9′ duct package including clean out and ARV
Heated air make-up system at 1.2 MBTU and 12,000 CFM with Deluxe controls
Heater duct package with intake and discharge duct
Inside dimensions:
24’ x 13’ 6” x 9’
Outside dimensions:
27’ 6” x 14’ x 11’ 3”
3″ double wall insulated panels
Powder coated white
Tri-fold product doors with (1) window in center door
Personnel door with window
(12) LED light fixtures
(1) 30” exhaust fan with 9′ duct package including clean out and ARV
Heated air make-up system at 1.2 MBTU and 12,000 CFM with Deluxe controls
Heater duct package with intake and discharge duct
Inside dimensions:
26’ x 14’ x 9’
Outside dimensions:
29’ 6” x 14’ 6” x 11’ 3”
Galvanized
Tek screw construction
Solid product doors without windows
Personnel door with window
(12) 4-tube inside access T8 light fixtures
(1) 30” Exhaust fan – 10,000 CFM
(1) 30″ x 9′ duct package including clean out and ARV
Inside dimensions:
24’ x 13’ 6” x 8’
Outside dimensions:
27’ 6” x 14’ x 10’ 3”
No upper plenum
Galvanized
Nut & Bolt / Tek screw construction
Solid product doors without windows
Personnel door with window
(10) 4-tube T8 light fixtures
(1) 30″ Exhaust fan – 10,000 CFM
(1) 30” x 9′ duct package including clean out and ARV
Inside dimensions:
26’ x 14’ x 9’
Outside dimensions:
26’ 5” x 14’ 5” x 9’ 3″
Pre-filtered upper plenum
Galvanized
Nut & Bolt / Tek screw construction
Solid product doors without windows
Personnel door with window
(10) 4-tube T8 light fixtures
(1) 30″ Exhaust fan – 10,000 CFM
(1) 30” x 9′ duct package including clean out and ARV
Inside dimensions:
26’ x 14’ x 9’
Outside dimensions:
26’ 5” x 14’ 5” x 11’
Galvanized
Nut & Bolt / Tek screw construction
Solid product doors without windows
Personnel door with window
(10) 4-tube T8 light fixtures
(1) 30” Exhaust fans with 9′ duct package including clean out and ARV
Heated air make-up system at 1.0 MBTU and 10,000 CFM with Deluxe controls
Heater duct package with intake and discharge duct
Inside dimensions:
26’ x 14’ x 9’
Outside dimensions:
26’ 5” x 14’ 5” x 11’
